uv wide format digital printer flatbed roller Canvas printing Machine YC3321R

Products Description PrintheadRICOH GEN5/GEN6
Printhead 2-8 unitsImage QualityBright picture,
fresh as before.PrintheadRICOH GEN5/GEN6
Printhead 2-8 units Product Paramenters

YC3321R UV Hybrid Printer

①UV LED Lamp②Anti-static,Anti-crash
⑦Industrial Printhead
③TAIWAN HIWIN guide rail
④Switch and power switch area
⑤Top Heavy Rubber Roller⑥Universal wheel

Specifications
Product Model	YC3321R
Printhead Type	RICOH GEN5/GEN6/KM1024I/SPT1024GS
Printhead Number	2-8 heads
Ink Characteristics	UV Curing Ink (VOC Free)
Ink reservoirs	Refillable on the fly while printing 2500ml per color
LED UV Lamp	more than 30000-hours life made in Korea
Printhead arrangement	CMYK LC LM W V Optional
Printhead Cleaning System	Automatic Cleaning System
Guide rail	TAIWAN HIWIN/THK Optional
Working Table	Vacuum Sucking
Printing Size	3300*2100mm
Roller Material Width	3300mm
Roller Material Diameter	200mm
Print Interface	USB2.0/USB3.0/Ethernet Interface
Media Thickness	0-100mm
Print Resolution& Speed	720X600dpi	4PASS	15-33sqm/h	(GEN6 40% faster than this speed)
		720X900dpi	6PASS		10-22sqm/h
		720X1200dpi	8PASS		8-18sqm/h
Life of printed image	3 years(outdoor),10years(indoor)
File Format	TIFF,JPEG,Postscript,EPS,PDF etc.
RIP Software	Photoprint Ntek Edition/RIP
Power Supply	220V 50/60Hz(10%)
Power	8500W
Operation Environment	Temperature 20 to 30 ℃,Humidity 40% to 60%
Machine Dimension	5.37*3.78*1.46m
Packing Dimension	5.55*2.25*1.67m 4.3*0.85*1.22m
Weight	3000kg
Warranty	12 months exclude the consumables related to ink, such as ink filter, damper etc
Above specification subject to change without notice beforehand

Machine Details

German IGUS Energy ChainGermany IGUS Mute Drag ChainUtilize Germany IGUS mute drag chain on X axis,ideal for protection of cable and tubes under high speed motion.With high per-formance,low noise,make the working environment more comfortable.



High Precision Aluminum BeamEquipped with self-researched cold draw and high-strength aerial aluminium material,it ensures printing precision and stability,guarantee the perfect output.


Ricoh Print HeadAdopting gray level Ricoh stainless steel internal heating industry head which has high performance in speed and resoluti-
on.It is suitable for long-time working, 24 hours running.

Vacuum Adsorption Platforem
Hard oxidized honeycomb hole srctiona-lized adsorption platform,strong adsorp-tion capacity,low mater consumption, customers can adjust the Adsorbed accor-ding to the side of the printing materialthe platform surface hardness is high,scratch resistance,corrosion resistance.

Universal

wheel

Secondary

Ink Cartridge

Korea UV

LED Lamp Adopt Ricoh piezoelectric nozzle, one nozzle 384/1280 nozzles, the accuracy can reach 1440dpi, the new variable ink drop technology, provide 7/14/21pl ink dot size, can achieve high speed or low resolution cases can also easily achieve high quality picture, to achieve no point printing effect.CMYK+W+V All three colors at onceThe use of gloss oil makes the product more gorgeous gloss and "high gloss" effect, not only makes the surface of the whole picture has a gloss sense, get a more exquisite printing effect, but also can better protect the coating, make the product more durable. Printing Samples Advertising PenBottle PVCGlassceramic fiberwoodmouse pad Company Profile Jinan Yingcai Digital Technology Co., Ltd
Jinan Yingcai Digital Technology Co., Ltd ( short as”Winscolor”) was established in 2015, locating in Jinan City, Shandong province, China. The independent plant covers more than 20,000 square meters, with six professional production lines to support annually sales volume.Winscolor is an exporter of UV digital printing machines . Now our printer series include UV Flatbed
printer, UV Flatbed with Roll to roll printer, and UV Hybrid printer, as well as smart UV printer.
Winscolor digital printing machine was exported since 2015, with widespread praise and recognition by our customers, our printers are welcome more than 150 countries in Asia, Europe, Australia and Africa etc.
Winscolor UV printers have been widely used in advertisement, sign,decoration, glass, crafts and other industries. We strengthen technological innovation, optimize the cost of consumption, and strive to create the best quality UV digital printing machines for our customer, and some comprehensive solutions according to different demands in various industries.
Winscolor uphold the concept of excellence, and continuously improve product quality, to become the most trusted brand in UV printing equipment industry. We will continue to committed to industrial printing R & D and innovation and promote the healthy development of printing industry. Packing & Delivery Customer Photos FAQ 1.How long does the printing images will last outdoors and indoor?
The printing images can last at least 3 years outdoors, and more than 10 years indoor.

2. How about the stability and quality of the printing images?
This UV flatbed printer can used to print on most of medias with best quality, durability,best result.

3. How about the maintenance and after sales service?
Our engineer available service overseas, and we can provide remote control service and online service for customers.But customer has to be responsible for the accommodation and transportation costs of the technical staff.
4.Are you a manufacturer or trade agent?
We are the manufacturer of Uv flatbed printers.

5. Is there any guarantee for this printer?
Yes, we have guarantee for the printer. We provide one year warranty for all the electronic parts including the main board, driver board, control board, motor, etc. But there is no warranty for wearing parts like ink pump, print head, ink filter, and slide block since they are consumables.

6. How can I install and start to use the printer?
At first, you should read the users' manual to understand the machine and watch the video. After you get the machine, our technician will teach you how to install and use machine by remote control via Team viewer or Skype. Whenever you have questions to the machine, you can contact our technician or me.

7.Can I get supplies and wearing parts from you?
Yes, we provide all the wearing parts for our printers always and they are in stock.

8. How will you achieve the warranty?
If any electronics or a mechanical part is confirmed to be broken, winscolor should send new part within 48 hours by express like TNT, DHL, FEDEX etc to the buyer. An shipping cost should be born by the buyer.

9. What kinds of materials need premier before printing？Glass, ceramic, metal, acrylic, marble etc.
